Infrared Photocell Sensor for Swing Sliding Gate Door 20M Detection Range

This infrared photocell sensor enhances the safety of automated swing and sliding gate systems by detecting obstacles within its range, effectively preventing accidental closures.

• Hard frosted design suitable for rough weather conditions
• Infrared technology for automatic beam detection
• Detection range up to 20M (range may reduce by 30% in poor weather)
• Operating temperature range -20°C to +70°C
• Power supply 12-24 DC/AC
• Relay output 1A max 30V
• Assembly required

• Technology: Infrared Photocell
• Receiver range: ≤20m
• Frequency: 1.92KHz
• Wavelength: 940mm
• Input: RX 15mA-TX 30mA
• Angle: ＜±10°
• Working temperature: -20°C to +70°C
• Product weight: approx. 0.2kg
• Product dimensions: approx. 7.5 x 4.9 x 3cm
• Available options: White

• Infrared photocell x2
• User Manual x1
